Description
*Note: This product has a 10 week lead time.
FREE GROUND SHIPPING TO THE CONTIGUOUS 48 STATES.
This 20" electric, single-speed Super Vac Smoke Ejector packs high-powered air movement — all while running on a 15-amp household
circuit — perfect for departments with larger residential buildings in their jurisdictions. This fan pulls smoke from structures using negative
pressure but can be flipped around for positive pressure tactics. Smoke ejectors are most effective when working with natural airflow
and not against Mother Nature.
Patented 4-Tip Recurved Aluminum Blade: Creates a tight spiral of air to eject smoke
and fumes away from the building; aluminum holds up better than plastic in high heat.
Precision-Balanced Blade: Maximizes output.
Heavy-Duty Rubber Feet: Adds friction to keep fan in place.
4 Carry Handles: Makes transportation easy with one or two people.
Front and Rear Guards: Prevents accidental contact with key components.
Motor: Bluffton Totally Enclosed Air Over (TEAO) Electric
Horsepower: 1 HP
Power: 115/230V AC, 50/60Hz
Speed: 1,725 rpm
Output: 9,800 cfm
Dimensions: 25.5" high x 24.75" wide x 16.25" deep
(650 mm x 630 mm x 415 mm)
Weight: 85 lbs.
The smoke ejector shall have a minimum five (5) year warranty. The motor shall be
warranted by the motor manufacturer for a minimum of two (2) years.
