Description
*Note: This product has a 6 week lead time.
FREE GROUND SHIPPING TO THE CONTIGUOUS 48 STATES.
NOTE: CALL OR EMAIL FOR YOUR SPECIAL PRICE. 417-831-7669 , greg@kencofe.com
V18-BD-09-SP-WH: Variable-Speed Battery Fan.
*WITH SHORE POWER.
*WITH 2 - DEWALT FLEXVOLT 9 AH BATTERIES AND 2 - AC CHARGERS.
Introducing the all-new VMAX Super Vac variable-speed battery fan that produces 30% more output on standard high-speed operation and also features a “MAX Mode”
that will increase your output up to 40% more at the push-of-a button. Super Vac’s 16", 18" and 20" variable-speed battery fans work with DeWalt®,
System batteries, making this lineup the most compatible PPV interface on the market.
A Super Vac’s V-MAX 16", 18" and 20" variable-speed battery fans shall be
supplied. The unit shall be designed with a lightweight roll-cage frame with
strategic placement of bracing members to enable easy carrying of the fan.
The entire frame of the unit shall be constructed of aluminum that shall surround
the shroud and a six-blade airfoil propeller in a roll-cage design.
The shroud and the safety grill shall be designed to provide maximum air velocity.
The positive pressure ventilator shall have 180-degree tilt capability. The front
and rear safety guards shall be designed to OSHA, CE and U.L. Standards to
prevent accidental contact with the blade.
The fan shall be:
• AMCA Standard 240-22 Certied
• Tested to DIN Standards
• EMI compliant and CE Certied
• IP Rated
The PPV shall have a minimum ve (5) year warranty. The battery and charger are
warranted by Makita for three (3) years. See makitatools.com for details. Motor
shall be warranted for a minimum of three (3) years.
1. Compact, Roll-Cage Frame: Features a tough yet
lightweight aluminum frame to protect key components
while providing a compact, lightweight design
2. Fold-Down Ergonomic Handle: Folds into the frame
for compact storage; features full-width handle for easy
grip with heavy-duty gloves
3.
Flat-Proof Rubber Tires: Highly maneuverable,
and all without lifting the fan; easy to deploy by the
smallest reghters.
4. 180-Degree Tilt: Provides the largest tilt range among
battery fans, allowing airow to be directed virtually anywhere.
5.
Non-Proprietary Batteries: Choose the battery that
works with your existing battery-power tool platform.
6.
Polymer Blade: Minimizes weight; Super Vac’s single-piece
cast aluminum blade is available by request
7.
Precision-Spun Steel Shroud with StreamShaper
Guard: Provides durability with max airow, while the
StreamShaper guard allows for exible setback;
Air Cone Guard available by request
8.
MAX Mode: Output CFM/CMH increases up to 40% more
at the push-of-a-button.
The variable-speed battery fan shall be designed with the following:
Motor: Brushless Variable-Speed DC
Power: 2 HP, 1.5 kW
High-Speed:
20" = 12,727 cfm (21,623 cmh)
Max Mode:
20" = 21,623 cfm (22,989 cmh)
Dimensions:
20" = 28.5" x 28.75" x 12.5" (720 mm x 730 mm x 315 mm)
Weight:
20" = 60 lbs. (27 kg) - without batteries
